Deskripsi
| S3148 / S3148P | S3124 / S3124F / S3124P | S3048-ON | |
| Chassis | |||
| Approximate Weight in pounds | 13.8891 / 15.2119 | 13.2277 / 13.2277 / 14.5505 | 12.8 |
| Approximate Weight in kilograms | 6.3kg / 6.9kg | 6kg / 6kg / 6.6kg | 5.8kg |
| Power Supply (Watts) | 200 | 200 / 200 / 715 or 1100 | 1100 |
| Max Thermal Output (BTU/hr) | 221.11 / 7319.04 | 182.55 / 228.96 / 4391.42 | 216 or 290 |
| Power Consumption Max (Watts) | 64.8 / 2145 | 53.5 / 67.1 / 1287 | 87 |
| Dimensions in inches (H x W x D) | 1.7126 x 17.0866 x 16.0236 | 1.7126 x 17.0866 x 16.0236 | 1.7126 x 17.0866 x 16.0236 |
| Dimensions in millimeters (H x W x D) | 43.5 x 434.0 x 407.0 | 43.5 x 434.0 x 407.0 | 43.5 x 434.0 x 407.0 |
| Environmental Operating Conditions | |||
| Operating temperature | 0° to 45°C (32° to 113° F) | ||
| Storage temperature | -40° to 65° C (-40° to 149° F) | ||
| Operating relative humidity | 95% | ||
| Storage relative humidity | 85% | ||
| Power Supply Efficiency: | 80% or better in all operating modes | ||
| Performance | |||
| Switch fabric capacity | 260Gbps | 212Gbps | 260Gbps |
| Forwarding rate | 193Mpps | 158Mpps | 131Mpps |
| Packet buffer memory | 4MB | 4MB | 4MB |
| Port Attributes | |||
| 1GbE Port Attributes Multi-speed | 48x RJ45 auto-sensing (1Gb/100Mb/10Mb) PoE+ fixed ports | 24x RJ45 auto-sensing (1Gb/100Mb/10Mb) fixed ports | 48x RJ45 auto-sensing (1Gb/100Mb/10Mb) fixed ports |
| Integrated 10GbE SFP+ dedicated ports (10 Gbps) | 2 | 2 | 2 |
| Power-over-Ethernet Plus (PoE/PoE+) Ports | N / S | N / N / S | N |
| Auto-negotiation for speed and flow control | S | S | S |
| Auto MDI/MDIX | S | S | S |
| Flow-based port mirroring | S | S | S |
| Broadcast storm control | S | S | S |
| Energy Efficient Ethernet per port settings | S | S | S |
| Port Profile support including Admin profiles | S | S | S |
| Management- & Configuration-Port Attributes | |||
| 1 RJ45 console/management port with RS232 signaling | Front | Front | Front |
| 1 Out-of-Band (OOB) Management Port (10/100/1000BASE-T) | Front | Front | Front |
| 1 USB (Type A) port for configuration | Front | Front | Front |
| Power & Cooling Hardware | |||
| Internal hot swappable power supply bays | 2 | 2 | 2 |
| Hot swappable power supplies (included) | 1 | 1 | 1 |
| Integrated power supply (not removable) | N | N | N |
| External power supply | N | N | N |
| Power supply redundancy | OA | OA | OA |
| Removable fans | N | N | N |
| Variable speed fans | S | S | S |
| Air flow | IO to PSU (Normal) | IO to PSU (Normal) | IO to PSU (Normal) |
| Switch Attributes | |||
| Line-rate Layer 2 switching | S | S | S |
| Line-rate Layer 3 routing | S | S | S |
| Dual firmware images on-board | S | S | S |
| Temperature sensors for environmental monitoring | S | S | S |
| Cable diagnostics | S | S | S |
| Optical transceiver (SFP/SFP+) diagnostics | S | S | S |
| Switch auditing support | S | S | S |
| CPU Memory | 2GB | 2GB | 2GB |
| Flash Memory | 256MB | 256MB | 256MB |
| Modules (optional) | |||
| 2-port 10 Gigabit BASE-T RJ45 hot swappable uplink module | OA | OA | N |
| 2-port 10 Gigabit SFP+ hot swappable uplink module | OA | OA | N |
| 2-port 40 Gigabit QSFP+ hot swappable module | N | N | N |
| Power Supplies (optional) | |||
| 200w, hot swappable, with V-Lock, adds redundancy to non-PoE switches | OA / N | OA / OA / N | N |
| 715w, hot swappable, adds redundancy or to power all PoE+ ports fully | N | N / N / OA | N |
| 1100w, hot swappable, adds redundancy or to power all PoE+ ports fully | N / OA | N / N / OA | N |
